15inch Sharp LQ150x1lg96 TFT LVDS Panel

Min. Amri:1 Piece/Pieces

Sifa za Bidhaa
Ufungaji & Utoaji
Other information

Sifa za Bidhaa

Mfano wa Mfano.: LQ150X1LG96

Ufungaji & Utoaji

Kuuza Vitengo:

Piece/Pieces

Utangulizi wa bidhaa

Joto la kufanya kazi la LQ150X1LG96 ni 0 ~ 65 ° C, na joto la kuhifadhi ni -30 ~ 70 ° C. Inafaa kwa matumizi ya viwandani, mambo muhimu ya nje, michezo. Matibabu ya uso ni matte, mipako ngumu (3H), na uzani wa bidhaa ni 950g (max.). Kwa upande wa Backlight, chanzo cha aina ya upande kina maisha ya masaa 30k.

Azimio la kuonyesha LQ150x1lg96 ni 1024 (RGB) × 768 (XGA), uwiano wa kipengele ni 4: 3 (upana: urefu), na saizi zimepangwa katika viboko vya wima vya RGB. Saizi ya eneo la kuonyesha la LQ150X1LG96 ni 304.128 × 228.096 (w × h) mm, saizi inayoonekana ni 307.2 × 231.1 (w × h) mm, na saizi ya nje ni 326.5 (w) × 253.5 (h) × 10.1 (d) mm.

brand	Sharp	Model name	LQ150X1LG96
size	15inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768 [XGA] 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	307.2×231.1mm(H×V)	Contrast Ratio	800:1 (Typ.) (TM)
Brightness(cd/m²)	1050cd/m²(Typ.)or customized	Outline dimension	326.5×253.5×10.1 mm(H×V×D)
Viewing Angle	80/80/60/80 (Typ.)(CR≥10)	work environment	Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C
Signal interface	LVDS (1 ch, 6/8-bit),erminal,20 pins
supply voltage	3.3V (Typ.)

LCD Panel
