Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Mfano wa Mfano.: LQ156M1LG21
LQ156M1LG21 ina azimio la kuonyesha la 1920 (RGB) × 1080 (FHD), uwiano wa kipengele cha 16: 9 (upana: urefu), na saizi zimepangwa katika viboko vya wima vya RGB.
Saizi ya eneo la kuonyesha la LQ156M1LG21 ni 344.16 × 193.59 (w × h) mm, saizi inayoonekana ni 349.0 × 198.4 (w × h) mm, saizi ya nje ni 370 × 217 (w × h) × 9.8 (d) mm, Matibabu ya Matibabu Matte kumaliza, mipako ngumu (3H), uzani wa wavu 950g (max.)
Kwa upande wa taa ya nyuma, chanzo cha taa ya taa inayotoa mwanga hutumiwa, na maisha ya huduma ya chanzo cha taa ni masaa 50k. Joto la kufanya kazi la LQ156M1LG21 ni 0 ~ 70 ° C, na joto la kuhifadhi ni -30 ~ 70 ° C.
| brand | Sharp | Model name | LQ156M1LG21 |
| size | 15.6inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD | Pixel configuration | RGB vertical bar |
| Display Area | 344.16×193.59(H×V)mm | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 349.0×198.4(H×V)mm | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 370×217×9.8(H*V*D) mm |
| Viewing Angle | 80/80/80/65 (Typ.)(CR≥10) | work environment | Storage temperature: 0 to 70 °C Operation Temperature: -30 to 70 °C |
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Vitambulisho vya Moto: LQ156M1LG21 New Sharp TFT-LCD Moudle, Uchina, Kiwanda, Nafuu, Bei, Imeboreshwa, Nukuu, Dirisha linalowakabili LCD, 15inch 1000nits LCD Screen, LCD ya juu, nje ya TFT LCD, 55 Inch Outdoor Screen, High Bright Jopo 49 inch, skrini mkali , jopo la LCD, moduli ya LCD, onyesho la juu la mwangaza.
