23.5 "CSOT MG2350S01-1 Uainishaji

Min. Amri:1 Piece/Pieces

Sifa za Bidhaa
Ufungaji & Utoaji
Other information

Sifa za Bidhaa

Mfano wa Mfano.: MG2350S01-1

Ufungaji & Utoaji

Kuuza Vitengo:

Piece/Pieces

Utangulizi wa bidhaa

Joto la kufanya kazi la MG2350S01-1 ni 0 ~ 50 ° C, na joto la kuhifadhi ni -20 ~ 60 ° C. Inafaa kwa alama za dijiti na skrini ya kukata bar.

Azimio la kuonyesha la MG2350S01-1 ni 1920 (RGB) × 360, ukubwa wa eneo lake ni 584.64 × 109.62 (upana × urefu) mm, saizi ya kuonekana ni 596.42 (upana) × 122.67 (urefu) mm, na matibabu ya uso ni Matte (haze 25%).

MG2350S01-1 inachukua LVDs (2 CH, 8-bit) interface ya ishara, jumla ya pini 30, zilizounganishwa na vituo, na voltage ya gari ni 12.0V (Typ.).

high brightness LCD

brand	CSOT	Model name	MG2350S01-1
size	23.5inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×360	Pixel configuration	RGB vertical bar
Display Area	584.64×109.62(H×V)mm	Surface treatment	Fog surface(Haze 25%)
Visual size	/	Contrast Ratio	4000:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	596.42×122.67(H×V)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Backlight type	WLED,Including LED driver
Signal interface	30 pins LVDS (2 ch, 8-bit)，erminal	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
supply voltage	12.0V (Typ.)

Vitambulisho vya Moto: 23.5 ＂CSOT MG2350S01-1 Uainishaji, Uchina, kiwanda, bei nafuu, bei, umeboreshwa, nukuu, windows inayowakabili LCD, skrini ndogo ya LCD, onyesho la windows la dijiti, 43 inch lcd kuonyesha skrini, inchi nje ya LCD, alama za LCD zinaonyesha. , Fungua moduli za LCD , jopo la LCD, moduli ya LCD, onyesho la juu la mwangaza.
