Mfano wa Mfano.: TDA150-005V01
TDA150-005V01 A-SI TFT-LCD Moduli ya glasi ya kioevu ya inchi 15, huduma za kawaida ni taa nyeupe za taa za LED, pamoja na dereva wa LED, uso wa matte. Joto lake la kufanya kazi ni -20 ~ 70 ° C, na joto lake la kuhifadhi ni -30 ~ 80 ° C. Azimio la kuonyesha ni 1600 (RGB) × 1200 (UXGA), na saizi zimepangwa katika viboko vya wima vya RGB. Saizi yake ya eneo la kuonyesha ni 304.8 × 228.6 (w × h) mm, na mwelekeo wa nje ni 317.4 (w) × 242 (h) mm.
Ni chanzo cha taa ya aina ya makali na maisha ya masaa 30k, pamoja na madereva wa LED. TDA150-005V01 inachukua interface ya ishara ya LVDs (2 CH, 8-bit), jumla ya pini 40, ambazo zimeunganishwa na vituo, na voltage ya gari ni 3.3V (Typ.).
Swali: Sisi ni akina nani?
A: R-Star ilitoka kwa Shenzhen, Uchina, sisi ni mtengenezaji wa kitaalam wa LCD ya mwisho wa juu, tunaweza kutoa kutoka moduli za 10.1 hadi 120 zinazoangazia TFT LCD, kuna wafanyikazi zaidi ya 100, pamoja na wahandisi wenye uzoefu 20. Kampuni imepitisha ISO9001/ISO14001/CCC/CE/FCC/ROHS/UL na udhibitisho mwingine, ina jukwaa la kiwango cha juu cha R&D, na imekuwa mshirika wa ODM/OEM wa kampuni nyingi za kiwango cha ulimwengu. Amerika, Afrika, Mashariki ya Kati, Ulaya, Amerika ya Kati na Kusini na Oceania.Tuamini kwamba ikiwa utatupa nafasi ya kutumikia, tutakuwa muuzaji wako anayeaminika nchini China.
Swali: Je! Wewe ni mtengenezaji (kiwanda)?
A: Ndio, tuko. Pia huduma ya OEM/ODM inapatikana hapa.welcome kushiriki maoni yako na sisi. Ni raha yetu kutoa suluhisho bora kwako.
Swali: Je! Tunawezaje kuhakikisha ubora?
A: ukaguzi wa mwisho kabla ya usafirishaji.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Saizi sawa na mfano ni kama ifuatavyo:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
